ABB CAI20-P

ABB CAI20-P

Product information：

Brand：ABB                             Model number：CAI20-P

Condition：new                              Warranty: 12 month

Lead Time：3-day working da        Country of origin: Sweden

Price: Please contact us                   Product weight：0.17KG

HS: 8517623990

Product technial information：

The ABB CAI20-P (also referred to as CAI 20) is an analog input module designed for industrial automation systems, specifically integrated with the ABB Symphony Plus control architecture.

Here's a detailed breakdown:

Product Description

The ABB Symphony Plus CAI20-P is an advanced analog input module primarily used in industrial automation systems. It enhances data acquisition and process control by providing accurate measurement for a wide range of analog signals. It typically features 20 or 32 channels and supports both current (0/4-20 mA) and voltage (0-10 V) signals. The module includes integrated HART communication, electrical isolation, and a short-circuit-proof transmitter power supply. Its robust design ensures reliable operation in demanding industrial environments.

Product Parameters

• Model: CAI20 / CAI20-P

• Part Number (Common): 3BDH000722R1, P 72122-4-0788 722

• Channels: 20 or 32 analog inputs

• Signal Types:

• Current: 0/4-20 mA (Signal scope: 0-22.5 mA)

• Voltage: 0-10 V (Signal scope: 0-11.5 V)

• HART Protocol: Versions 5.0 / 5.1 supported

• A/D Conversion: 12-bit resolution

• Electrical Isolation: Full isolation per module (group-wise per termination unit)

• Transmitter Power Supply: Short-circuit-proof

• Operating Temperature: 0°C to 50°C

• Supply Voltage: 20-33 V DC (nominal 24 V ±10%)

• Current Consumption:

• Transmitter supply off: ~195 mA @ 24 V

• Transmitter supply on: ~865 mA @ 24 V (η = 0.75)

• Power Loss: Max. 11 W @ 24 V

• Memory (for control processors): RAM: 128 MB, ROM: 4 MB, NVRAM: 512 KB

• Dimensions: 212 mm (Depth) × 350 mm (Height) × 55 mm (Width)

• Weight: 0.76 kg

Product Advantages

• High Signal Precision: Engineered to minimize signal drift and noise, providing accurate data.

• Multichannel Input Support: Capable of handling multiple analog signals simultaneously.

• Broad Signal Compatibility: Accepts signals from various sources like thermocouples, RTDs, and voltage/current transmitters.

• Robust Design: Built to withstand harsh industrial applications, resistant to dust, heat, and electromagnetic interference.

• Seamless Integration: Compatible with ABB's Symphony Plus control architecture, PLC, and other common control platforms.

• Reliability and Longevity: Known for robust performance and accurate operation, minimizing downtime.

• Advanced Features: Supports HART communication, offers electrical isolation, and a short-circuit-proof transmitter supply.
