ABB ICSO08Y1

ABB ICSO08Y1

Product information：

Brand：ABB                             Model number：ICSO08Y1

Condition：new                              Warranty: 12 month

Lead Time：3-day working da        Country of origin: Sweden

Price: Please contact us                   Product weight：0.19kg

HS: 8517623990

Product technial information：

The ABB ICSO08Y1 is a digital output module, specifically an 8-channel, 24 V DC, 2 A unit, designed for use as a remote module within the ABB Procontic CS31 intelligent decentralized automation system.

Here's a detailed breakdown:

Product Description

The ICSO08Y1 module features 8 output channels that are electrically isolated, operate with transistors, and are protected against overload and short-circuits. It is available for both 24 V DC and 230 V AC supply voltages and must be mounted on an ECZ plug-in base for electrical connection. The module includes diagnostic functions, indicated by 8 yellow LEDs for signal status and a red LED for error messages. It also has a test button for diagnosis. The CS31 system bus interface is electrically isolated from the rest of the module.

Product Parameters

• Channels: 8 output channels

• Rated Voltage: 24 V DC

• Max Load per Channel: 2 A (Note: Minimum load must be > 50 mA for safe OFF state; ICSC 08 L1 is recommended for loads below 50 mA.)

• Outputs: Electrically isolated, transistor-based, overload and short-circuit proof.

• Dimensions: 12.2 cm (length) x 9.5 cm (width) x 6.3 cm (height)

• Weight: 0.32 kg

• Country of Origin: Sweden

• Compatibility: Designed for the CS31 system bus.

Product Advantages

Being part of the ABB Procontic CS31 system, the ICSO08Y1 contributes to several advantages:

• Decentralized Architecture: Offers a cost-effective alternative to centralized systems, potentially reducing wiring costs by up to 80% due to the ability to mount I/O units locally to sensors and actuators.

• Modularity and Expandability: The system is highly modular, allowing for easy expansion and the addition of new units even while the installation is operational.

• Extensive Diagnosis Functions: Includes built-in diagnostic capabilities for easier troubleshooting.

• Simple and Transparent Programming: Remote I/O channels are handled as though they were centralized, simplifying programming.

• Easy Interchangeability: Remote units are plug-in base mounted, making them easily interchangeable, even during operation.

Precautions

• Minimum Load: A minimum load of greater than 50 mA is required for the outputs to ensure a safe OFF state. For loads below 50 mA, the ICSC 08 L1 module is recommended.

• Installation Rules: Adherence to specific installation rules is crucial, including proper grounding, correct connection of the CS31 bus (RS 485, using the same type of cable throughout), and appropriate power supply installations.

• Safety Regulations: Compliance with national and international regulations such as DIN VDE 0100, DIN VDE 0110, DIN VDE 0160, and IEC 1131 Part 2 is necessary for safe operation. Protection against direct contact and proper measures for overvoltage categories must be ensured by the user.

Product Applications

The ABB ICSO08Y1, as a remote digital output module within the CS31 system, is primarily used in automation applications where:

• Modularity and Cost Reduction are key factors, benefiting from the decentralized architecture and reduced wiring.

• Control Systems require distributed input/output capabilities, allowing the central unit to connect to remote units along a process line.

• Industrial Automation scenarios where control of 24 V DC, 2 A loads is needed, such as operating actuators, indicators, or other digital outputs.
