ABB AI810 Modules

ABB AI810

Product information：

Brand：ABB                             Model number：AI810

Condition：new                              Warranty: 12 month

Lead Time：3-day working da        Country of origin: Sweden

Price: Please contact us                   Product weight：0.17KG

HS: 8517623990

Product technial information：

The ABB AI810 is an Analog Input Module designed for industrial automation applications, primarily as part of ABB's S800 I/O system. It's used to convert analog signals from field devices into digital data that a control system (like an AC 800M controller) can understand and process.

Product Details

The AI810 module features 8 channels, each capable of handling either voltage or current inputs. It's designed for single-ended, unipolar inputs and offers a 12-bit resolution for accurate signal conversion.

Key features include:

• Input Types: Supports 0-20 mA, 4-20 mA, 0-10 V, or 2-10 V DC signals.

• Isolation: One group of 8 channels is isolated from ground, which helps prevent ground loops and improves signal integrity.

• Protection: Input shunt resistors are protected to 30 V DC by a PTC (Positive Temperature Coefficient) resistor, offering protection against short circuits to the transmitter supply. Analog inputs are also short-circuit secured to ZP or +24 V.

• HART Communication: The input withstands HART communication, allowing for advanced diagnostic and configuration capabilities with HART-enabled field devices.

Product Parameters

Here are some key technical specifications for the ABB AI810:

• Number of Channels: 8

• Resolution: 12 bit

• Input Impedance:

• Voltage input: 290 kΩ

• Current input: 230 - 275 kΩ (PTC included)

• Maximum Non-Destructive Input Voltage: 30 V DC

• Update Cycle Time: 8 ms

• Input Filter (Rise Time 0-90%): 140 ms

• Error: Max. 0.1%

• Temperature Drift:

• Voltage: Typ. 70 ppm/°C, Max. 100 ppm/°C

• Current: Typ. 50 ppm/°C, Max. 80 ppm/°C

• Isolation: Groupwise isolated from ground

• Rated Insulation Voltage: 50 V

• Dielectric Test Voltage: 500 V AC

• Power Dissipation: 1.5 W

• Maximum Field Cable Length: 600 meters (656 yards)

• Dimensions:

• Width: 45 mm (1.77”)

• Depth: 102 mm (4.01”), 111 mm (4.37”) including connector

• Height: 119 mm (4.7”)

• Weight: 0.2 kg (0.44 lbs.)

• Operating Temperature: 0 to +55 °C (+32 to +131 °F) (approvals are typically for +5 to +55 °C)

• Storage Temperature: -40 to +70 °C (-40 to +158 °F)

• Relative Humidity: 5 to 95 %, non-condensing

• Protection Class: IP20 according to IEC 60529

• Certifications: CE mark, EN 61010-1, UL 61010-1, EN 61010-2-201, UL 61010-2-201, C1 Div 2 cULus, C1 Zone 2 cULus, ATEX Zone 2, ABS, BV, DNV, LR (Marine certification).
