Allen-Bradley 1492-IFM20F-FS-2

Allen-Bradley 1492-IFM20F-FS-2

Product information：

Brand：ALLEN-BRADLEY                        Model number：1492-IFM20F-FS-2

Condition：new                              Warranty: 12 month

Lead Time：3-day working da        Country of origin: United States

Price: Please contact us                   Product weight：0.12kg

HS: 8517623990

Product technial information：

Allen-Bradley 1492-IFM20F-FS-2 Product Details

The Allen-Bradley 1492-IFM20F-FS-2 is a 20-pin, fused isolated digital interface module (IFM) designed to connect digital I/O devices to programmable logic controllers (PLCs). It features 5x20 mm fuse clips and extra terminals for outputs, providing a convenient and reliable wiring solution. This module is part of the Allen-Bradley 1492 wiring system, which aims to simplify control panel wiring, reduce errors, and improve aesthetics.

Product Parameters

• Product Type: Digital Module with Fixed Terminal Block

• Interface Module Style: Fused Isolated

• Number of Pins: 20

• Field Side Terminals: Two per I/O connection

• Fuse Size: 5 x 20 mm

• Voltage Rating: 0-132V AC/VDC

• Current Rating: 2 Amp per circuit, 12 Amp per module

• Temperature Rating: 0 to 60 degrees C (32 to 140 degrees F)

• Certifications: CE, CSA, CUL, KC, NRTL, UL

• Dimensions (H x W x L): Refer to manufacturer's datasheet (various sources provide slightly different dimensions, e.g., 10.414 cm x 11.176 cm x 17.272 cm or 83.06 mm x 59.94 mm x 70.61 mm)

• Weight: Approximately 0.263 kg (0.57 lbs)

Product Advantages

• Increased Productivity: Simplifies machine building and reduces wiring time.

• Reduced Errors: Minimizes the potential for wiring mistakes.

• Improved Panel Appearance: Contributes to a cleaner and more organized control panel.

• Flexibility: Suitable for interfacing with digital I/O from 8 to 16 points.

• Fused Protection: Offers circuit protection with easy-to-replace fuses.

• Isolated Channels: Provides electrical isolation between I/O channels.

• Blown Fuse Indication (FS version): Some versions include an indicator for blown fuses, aiding in troubleshooting.

• Extra Terminals for Outputs: Simplifies wiring for output devices.

• Wide Compatibility: Can be used with various Allen-Bradley I/O modules, including Bulletin 1746, 1756, 1769, 1794, and 1771 series.

Precautions

• Voltage and Current Limits: Do not exceed the specified voltage and current ratings of the module to ensure proper operation and prevent damage.

• Proper Wiring: Ensure all wiring connections are secure and correct according to the wiring diagram.

• Fuse Rating: Use fuses with the correct rating (5x20 mm) for proper circuit protection.

• Environmental Conditions: Operate the module within the specified temperature and humidity ranges.

• Installation: Follow the manufacturer's installation instructions carefully.

Product Applications

The Allen-Bradley 1492-IFM20F-FS-2 interface module is used in a wide range of industrial automation applications where digital input and output signals need to be connected to a PLC. Common applications include:

• Connecting sensors and actuators to PLC systems.

• Interfacing with control devices such as pushbuttons, switches, and relays.

• Providing a convenient wiring interface for digital I/O modules in control panels.

• Simplifying wiring in various industrial machinery and equipment.

• Used in systems requiring fused protection for digital output circuits.
