Allen-Bradley 1734-ADN

Allen-Bradley 1734-ADN

Product information：

Brand：ALLEN-BRADLEY                        Model number：1734-ADN

Condition：new                              Warranty: 12 month

Lead Time：3-day working da        Country of origin: United States

Price: Please contact us                   Product weight：0.23kg

HS: 8517623990

Product technial information：

The Allen-Bradley 1734-ADN is a POINT I/O DeviceNet adapter module, a crucial component in distributed I/O systems within industrial automation. It acts as a bridge, allowing various POINT I/O modules to communicate with a master controller over a DeviceNet network.

Product Description

The 1734-ADN is part of the Bulletin 1734 POINT I/O series, known for its compact, modular, and flexible design. It's designed for DIN rail mounting and serves as the communication interface between the local POINT I/O backplane and the DeviceNet network. This adapter module powers the I/O modules connected to its backplane.

Product Parameters

Here are some key technical specifications for the Allen-Bradley 1734-ADN:

• Module Type: DeviceNet Adapter Module

• Input Voltage: 24V DC (typically 23-28.8V DC range)

• Field Side Power: 400 mA

• Inrush Current: 6 Amps

• POINTBus Current: 1000 mA

• Power Consumption: 8.1 Watts (max)

• Power Dissipation: 2.8 Watts (at 28.8V)

• DeviceNet Communication Rate: Supports 125K, 250K, and 500K bits/second (with autobaud detection)

• I/O Module Capacity: Up to 63 POINT I/O modules per adapter

• Maximum I/O Points: Up to 504 points on a single network node

• Mounting: DIN rail

• Operating Temperature: -20 to 55 °C (-4 to 131 °F)

• Enclosure: Open-style (requires installation in a suitable enclosure)

Product Advantages

The 1734-ADN offers several benefits for industrial automation:

• Distributed I/O Implementation: Enables flexible and scalable distributed I/O systems, allowing you to place I/O closer to the field devices, reducing wiring costs and installation time.

• Compact and Modular Design: Its small footprint and modular nature save valuable panel space and allow for "just enough" I/O where needed, with 1, 2, or 4-point granularity.

• Easy Integration: Seamlessly integrates with other Allen-Bradley products and the Studio 5000 Logix Designer® application through Add-on-Profiles, simplifying configuration and programming.

• Autobaud Feature: Automatically detects and sets the DeviceNet network baud rate, simplifying setup and ensuring reliable communication.

• Auto Device Replace (ADR): This feature allows for automatic configuration transfer from a removed device to a replacement module, minimizing downtime during maintenance.

• Comprehensive Diagnostics: Provides channel-level electronic diagnostics and alarming, aiding in quick troubleshooting and fault detection.

• Hot Swappable (RIUP): Supports Removal and Insertion Under Power (RIUP) for connected I/O modules, meaning modules can be replaced while the system is operational (with proper safety precautions in hazardous environments).

• Versatile Mounting: Can be mounted horizontally or vertically without derating.
