Allen-Bradley 1753-IB16

Allen-Bradley 1753-IB16

Product information：

Brand：ALLEN-BRADLEY                        Model number：1753-IB16

Condition：new                              Warranty: 12 month

Lead Time：3-day working da        Country of origin: United States

Price: Please contact us                   Product weight：0.65kg

HS: 8517623990

Product technial information：

The Allen-Bradley 1753-IB16 is a GuardPLC Digital Input Module designed for safety applications in industrial automation. It's part of the GuardPLC family, which focuses on providing reliable safety control in various environments.

Product Details

The 1753-IB16 is a 16-point, 24V DC safety digital input module. This means it can monitor the state of 16 different 24-volt DC input devices, such as emergency stops, safety gates, or light curtains, and communicate this information to a GuardPLC controller. A key feature of this module is its integrated GuardPLC 100 Mbps Ethernet interface, allowing for high-speed and secure communication within a safety system.

Product Parameters

Here are some typical specifications for the Allen-Bradley 1753-IB16:

• Manufacturer: Rockwell Automation (Allen-Bradley)

• Series: GuardPLC

• Input Type: Digital

• Number of Inputs: 16

• Operating Voltage: 24V DC

• Output Current: 60 mA (per output, though this is an input module, this might refer to internal current draw or diagnostic capability)

• Ethernet Ports: 2 x RJ-45, 10/100BaseT (with integrated switch)

• Weight: Approximately 0.7 kg (1.5 lbs)

• Dimensions: Approximately 114 x 152 x 66 mm

Product Advantages

• Safety-Rated: As part of the GuardPLC family, the 1753-IB16 is designed and certified for use in safety-critical applications, helping to meet international safety standards.

• High-Speed Communication: The integrated 100 Mbps Ethernet interface enables fast and efficient data exchange with other GuardPLC components, crucial for rapid response in safety systems.

• Robust Design: Built for industrial environments, it's designed to withstand typical industrial conditions.

• Simplified Wiring: As a digital input module, it simplifies the connection of multiple safety devices to a single module.

• Integrated Switch: The two Ethernet ports with an integrated switch allow for flexible network topologies, such as daisy-chaining, reducing the need for external network switches.

Important Considerations

When working with the 1753-IB16, keep the following in mind:

• Electrostatic Discharge (ESD): This equipment is sensitive to ESD. Always follow proper handling procedures, such as touching a grounded object, wearing a wrist-strap grounding device, and using a static-safe workstation. Avoid touching connectors, pins, or internal circuit components.

• Mounting and Enclosure: The module is supplied as open-type equipment and must be mounted within a suitable enclosure designed for the specific environmental conditions and to prevent access to live parts. The enclosure should have flame-retardant properties.

• Grounding: Ensure proper grounding. The module is functionally grounded through its DIN rail connection. Use zinc-plated yellow-chromate steel DIN rail to ensure effective and continuous grounding. Secure the DIN rail approximately every 200 mm.

• Cooling: For effective cooling, mount the module horizontally, provide at least a 100 mm (3.94 in.) gap above and below, and select a location with free airflow or use an additional fan. Do not mount it over a heating device.

• Power Supply Connection: Do not reverse the L+ and L- terminals, as this can damage the module. There is no reverse polarity protection.

• Software and Firmware: If purchasing pre-owned or surplus equipment, be aware that original manufacturer warranties and support may not apply. Additionally, you may need to obtain proper software or firmware licenses directly from Rockwell Automation, as these are typically not included with hardware purchases from unauthorized resellers.
