EMERSON KJ-1501X1-BB1

EMERSON KJ-1501X1-BB1 Product Details

The EMERSON KJ-1501X1-BB1 is a System DC/DC Power Supply Module designed for use with Emerson's DeltaV distributed control system. It is a passthrough power supply that operates with a 12 VDC input and provides a 12 VDC output. This module is also known under the part number 12P0678X042 VE5002.

Product Parameters

Here are some key specifications for the EMERSON KJ-1501X1-BB1:

• Manufacturer: EMERSON

• Part Number: KJ1501X1-BB1, 12P0678X042, VE5002

• Description: System DC/DC Power Supply Module

• Input Voltage: 12 VDC

• Output Voltage: 12 VDC

• Output Power: 10 W (maximum)

• Weight: Approximately 0.2 kg - 1.33 kg (sources vary)

• Dimensions: Approximately 13.0 cm x 1.9 cm x 19.1 cm (sources vary)

• Origin: USA / Thailand (sources vary)

• Warranty: Typically 1 year

Product Advantages

Based on the available information, potential advantages of the EMERSON KJ-1501X1-BB1 include:

• Reliability: As part of the Emerson DeltaV system, it is designed for robust and reliable operation in industrial environments.

• System Integration: Specifically designed for seamless integration with the DeltaV control system.

• Redundancy: Some sources indicate it can function as a redundant power supply module, enhancing system availability.

• Compact Design: Its dimensions suggest a relatively compact form factor.

Precautions

When handling and installing the EMERSON KJ-1501X1-BB1, it is important to observe the following precautions:

• Power De-energization: The unit cannot be removed or inserted while the system power is energized. Ensure the power supply is turned off before any installation or removal procedures.

• No User-Serviceable Parts: This unit contains no user-serviceable parts and should not be disassembled for any reason.

• Hazardous Area Installation: If the module is intended for use in hazardous areas, refer to the specific installation instructions (e.g., document 12P2046 or 12P5404 for Zone 2 installations) for proper procedures and safety guidelines. Ensure compliance with relevant safety standards and certifications (e.g., ATEX, IECEx, FM).

• Input Voltage Limits: If used in a 12 VDC passthrough mode, the voltage source should not exceed 12.6 VDC and should supply no more than 16 A maximum.
