EMERSON KJ2002X1-CA1

EMERSON KJ2002X1-CA1 Product Details

The Emerson KJ2002X1-CA1 is a controller module, specifically the Controller M5 Plus, designed for use within Emerson's DeltaV distributed control system (DCS). It plays a crucial role in managing and executing control strategies within industrial automation environments.

Product Parameters

Here are some key specifications and parameters for the EMERSON KJ2002X1-CA1:

• Model Number: KJ2002X1-CA1

• Alternate Part Number: 12P1509X102, VE3004 (This might vary slightly depending on the specific revision or configuration)

• Description: Controller M5 Plus

• LocalBus Power Rating: 3.3 VDC, 500mA Max; 5 VDC, 750mA Max

• Dimensions: Approximately 4.1 x 12.5 x 15.8 cm

• Weight: Approximately 0.34 kg (0.66 lbs as listed by some sources)

• Ambient Temperature: 60°C Max

• Mounting: DIN Rail Mount

• Integration: Designed for seamless integration with Emerson DeltaV systems.

Product Advantages

The EMERSON KJ2002X1-CA1 Controller M5 Plus offers several advantages:

• Seamless DeltaV Integration: Specifically designed for the DeltaV DCS architecture, ensuring compatibility and easy configuration with other DeltaV components.

• Robust Performance: Provides reliable performance for executing control strategies in demanding industrial environments.

• Scalability: As part of the DeltaV system, it supports modular system growth.

• Advanced Operations: Supports migration of PROVOX and RS3 controllers within the DeltaV platform.

• Redundancy Options: Can be implemented in a redundant configuration for increased system availability and reliability (requires an additional redundant controller).

• Future-Proofing: The DeltaV platform allows for software license expansion to accommodate increasing system complexity and control module scan rates as the system grows.

Precautions

When handling and installing the EMERSON KJ2002X1-CA1, it's important to observe the following precautions:

• Installation Environment: Ensure the module is installed in an enclosure that provides adequate protection against mechanical damage, electric shock, and fire. For hazardous locations, follow specific installation guidelines for Class I Division 2 or ATEX Zone II environments.

• Grounding: Metallic enclosures must have a protective grounding terminal, and all accessible non-current conductive parts should be bonded to this terminal with a resistance not exceeding 0.1 ohms.

• Accessibility: Mount the equipment so that internal circuits are only accessible with the use of a tool.
