Emerson DeltaV KL4503X1-DA1 12P5581X012

Welcome, thank you for your trust, The seller has more than $1526000 worth of industrial control products inventory.hope we can help you solve your problem!!!

  We Can transport to the world!!!

*******************************************************
Emerson  DeltaV KL4503X1-DA1 12P5581X012 Power module In Stock

The Thermocouple / mV Terminal Block is specially

designed for the usage with the Thermocouple / mV CHARM.

The Thermocouple / mV Terminal Block has ffxed key positions

to prevent a mismatch in the ffeld and can only be ordered

as an Assembly with the Thermocouple / mV CHARM.

The 3-wire AI Fused Injected Power Terminal Block is

designed for 3 wire analog transmitters and can be used with

the AI 4-20mA HART CHARM. The ffeld power is supplied from

the injected power bus on the baseplate, but the power is not

removed from the ffeld device when the AI CHARM is removed

from the baseplate. There is a Green LED on the terminal block

that indicated power is supplied to the ffeld and the 2A fuse

also functions as a means to disconnect power from the ffeld

device. Although this terminal block was introduced in 2017,

it is backwards compatible to any version of DeltaV with

Electronic Marshalling.

Although any signal type can be installed in any location on the

CHARM baseplates, it is recommended that AC voltage circuits

be separated from low voltage signals to comply with safety

recommendations and to mitigate induced noise in the signals.

Standard Terminal blocks, Fused Injected Power terminal blocks

and Relay Output Blocks can be used on the same carrier,

typically, to allow the use of DO 24V DC isolated CHARMs

on higher wattage and 3-wire devices alongside of standard

24V DC instrumentation signals or relay contacts.

Product details:

Emerson  DeltaV KL4503X1-DA1 12P5581X012 Power module

Contact information：

Contact person：Luna Chen

Email Address:：sales6@saulplc.com

WhatApp： +86 13358378970

We look forward to your inquiry and will get back to you as soon as possible.

We have the same series of models in stock. If you don't find the model you need, please contact us and we will provide you with an official quotation！
