FOXBORO P92204360100

Welcome, thank you for your trust, The seller has more than $1526000 worth of industrial control products inventory.hope we can help you solve your problem!!!

  We Can transport to the world!!!

*******************************************************

FOXBORO P92204360100 Power module In Stock

1. For detailed information on balun use and installation, see “Using the Cable

Balun Module with Intelligent Transmitters” in System Equipment Installation

(B0193AC).

2. Cable balun used only when multiple loops are connected to a common power

supply. The FBM negative terminals connect directly to the minus (-) terminal of

the power supply. The balun system side negative (-) terminals (2, 4, 6, and 8)

connect to the power supply positive terminals when there are 4 (maximum)

power loops.

3. For hazardous environments, install an intrinsic safety barrier such as an MTL

787S+ between the balun wiring to limit the amount of energy in the wiring.

4. A user-supplied capacitor can be installed across the external power supply(ies)

to shunt AC power.

5. The external power supply can be redundant power supplies in parallel.

6. For this transmitter connection, use twisted-pair wiring inside a shielded cable

with the shield grounded at the Foxboro DCS end.

• Supported HART Instruments:

HART instruments compliant to Version 5, 6, or 7 of the HARTspecifications may be

used

• Interface:

8 individually isolated channels

• Communication to the Device:

Point-to-point, master/slave, asynchronous, half-duplex, at 1200 baud

• Detected Error Checking:

Parity on each byte, and one CRC check byte

• Speed:

2 messages per second

• Fastest Allowed ECB Block Period:

100 msec - However, we recommend that you see the Sizing Guidelines and Excel

Workbook appropriate for your Control Processor to determine the optimal loading

for a 100 msec Block Processing Cycle (BPC)

Product details：

FOXBORO P92204360100 Power module

Contact information：

Contact person：Luna Chen

Email Address:：sales6@saulplc.com

WhatApp： +86 13358378970

We look forward to your inquiry and will get back to you as soon as possible.

We have the same series of models in stock. If you don't find the model you need, please contact us and we will provide you with an official quotation！
