GE IC693TCM302B Product Details

The GE IC693TCM302B is a Temperature Control Module (TCM) designed for use with GE Fanuc Series 90-30 programmable logic controllers (PLCs). It provides precise temperature monitoring and control for industrial automation applications. This high-performance module offers eight channels for thermocouple input and eight channels for control output within a single Series 90-30 slot. It can operate in either open-loop or closed-loop (PID) control modes, offering flexibility for various temperature control requirements. The module also features comprehensive error detection and reporting capabilities for thermocouples, enhancing system reliability.

Product Parameters

• Series: Series 90-30

• Module Type: Thermocouple Input / Temperature Control

• Number of Channels: 8 thermocouple inputs, 8 DC outputs

• Input Type: Thermocouple (J, K, L), RTD

• Temperature Range:

• 0 - 450 °C (J and L thermocouples)

• 0 - 600 °C (K thermocouple)

• Resolution: 12 bits / 0.2 °C

• Output Voltage Range: 18 to 30 VDC

• Load Current: 100 mA per output channel

• External Power Supply: 18 to 36 VDC (2.5 Amps inrush)

• Internal Power Consumption: 150 mA at 5 VDC

• Maximum Off-State Leakage Current: 0.1 mA

• Overload Threshold Current: 700 mA typical (2 ms minimum)

• Thermocouple Impedance: 30 Ohms (maximum)

• Common Mode Voltage Capability: ±12V

• Operating Temperature: 0 to 55 °C (32 to 131 °F)

• Storage Temperature: -40 to 85 °C (-40 to 185 °F)

• LED Indicators: 12 LEDs for thermocouple status, power, run, fault, and short circuit

• Fuse: 2 Amp, 125V user-replaceable fuse

Product Advantages

• High-Performance Temperature Control: Provides accurate and reliable temperature regulation for up to eight independent zones.

• Versatile Operation: Supports both open-loop and closed-loop (PID) control modes, adaptable to different application needs.

• Multiple Input Types: Compatible with J, K, and L thermocouples, as well as RTD inputs, offering flexibility in temperature sensing.

• Precise Measurement: 12-bit resolution ensures accurate temperature readings with a resolution of 0.2 °C.

• Comprehensive Diagnostics: Detects and reports open and reversed thermocouples, as well as out-of-tolerance temperatures, enhancing system safety and reliability.

• Visual Status Indication: 12 LED indicators provide clear feedback on the status of each thermocouple channel and the module itself.

• Easy Field Wiring: Utilizes plug-in connectors with captive screw terminals for convenient and secure wiring.

• Integration with Series 90-30 PLC: Seamlessly integrates with GE Fanuc Series 90-30 PLCs for unified control and monitoring.

• Automatic and Manual Modes: Offers both automatic PID control and manual duty cycle output for each zone.

• Programmable PWM Output: Each zone features a programmable Pulse Width Modulation (PWM) output (0.1 to 60 seconds) with a duty cycle resolution of 0.1%.
