HIMA F3331

HIMA F3331

Product information：

Brand：HIMA                               Model number：F3331

Condition：new                              Warranty: 12 month

Lead Time：3-day working da        Country of origin: Germany

Price: Please contact us                   Product weight：0.14kg

HS: 8517623990

Product technial information：

HIMA F3331 Detailed Description

The HIMA F3331 is an 8-channel, safety-related digital output module. It is part of HIMA's safety control systems, typically used in critical industrial applications requiring high levels of safety and reliability. This module is designed to interface with actuators, valves, relays, and other final control elements in safety instrumented systems (SIS).

Product Parameters

• Number of Channels: 8

• Output Type: Transistor (Open Collector)

• Output Voltage: 24 V DC

• Output Current: 500 mA per channel

• Safety Integrity Level (SIL): SIL 3

• Category: Cat. 4

• Short Circuit Protection: Yes

• Line Break Monitoring: Yes (requires a minimum load of 10 mA)

• Internal Voltage Drop: Max. 2 V at 500 mA load

• Admissible Line Resistance (in + out): Max. 11 Ohm

• Undervoltage Tripping: ≤ 16 V

• Short Circuit Current: 0.75 ... 1.5 A

• Line Break Detection: 0.5 ... 9.5 mA

• Output Leakage Current: Max. 350 µA

• Output Voltage if Output is Reset: Max. 1.5 V

• Current Input WD (Watchdog): Max. 30 mA

• Duration of Test Signal: Max. 200 µs

• Power Consumption (5 V DC): 130 mA

• Power Consumption (24 V DC additional load): 180 mA

• Space Requirement: 4 TE (Width Units)

• Dimensions: Typically around 22.5 mm x 100 mm x 121 mm

• Weight: Approximately 0.25 kg

Product Advantages

• High Safety: Suitable for safety-related applications up to SIL 3 and Category 4.

• Reliable Output Control: Provides dependable switching of output signals for critical devices.

• Integrated Diagnostics: Features like line break monitoring and read-back of output signals enhance fault detection.

• Short Circuit Protection: Protects the module and connected devices from damage due to overcurrent.

• Versatile Load Handling: Can handle resistive and inductive loads up to 500 mA, and lamp connections up to 4 W.

• Compact Design: 4 TE width allows for efficient use of control cabinet space.

• Automatic Testing: The module is automatically tested during operation, increasing safety and availability.

• Safe Isolation: Integrated safety shutdown with safe isolation ensures safe operation.

• No Output Signal on L-Supply Break: Prevents unintended activation of outputs in case of a power supply interruption.

• Can be Paralleled: Outputs can be paralleled without external diodes, offering flexibility in application design.
