HIMA F6705

Product information：

Brand：HIMA Model number：F6705

Condition：new Warranty: 12 month

Lead Time：3-day working da Country of origin: Germany

Price: Please contact us Product weight：0.28kg

HS: 8517623990

Product technial information：

HIMA F6705

HIMA F6705 Product Details

The HIMA F6705 is a 2-fold converter digital/analog, safety-related module designed for generating analog output signals (typically 0/4...20 mA) in HIMA safety systems. It features individual galvanic isolation and integrated safety shutdown capabilities, making it suitable for safety-critical applications. The module is automatically fully tested during operation, ensuring high reliability. It can be used in either source or sink mode.

Product Parameters

Outputs: 2 analog outputs, individually galvanically isolated.
Output Range: 0/4 to 20 mA.
Resolution: 12 bits (4095 steps).
Burden (RB):

Source Mode: ≤ 550 Ohm including line resistance.
Sink Mode: ≤ (UQ - 10 V) / 21.2 mA (UQ = source voltage).

Basic Error: ≤ 0.2% (40 µA) at 25 °C.
Operating Error: ≤ 0.4% at 0...+60 °C.
Line Length: Max. 1000 m (consider burden).
Electrical Strength: 250 V against Analog-GND.
Source Voltage (UQ, sink mode): 10...30 V DC.
Current Consumption:

5 V DC: 85 mA
24 V DC: 130 mA

Safety Integrity Level (SIL): Up to SIL 3 (IEC 61508).
Requirement Class: AK 1...6.
Space Requirement: 4 TE (Width units).
Redundant Current Connection: Supported with specific considerations for burden resistance and operating mode.
Bipolar Current Connection: Supported for outputting currents between -20 mA to +20 mA with specific configuration requirements.

Product Advantages

Safety-Related: Designed and certified for safety-critical applications up to SIL 3.
High Accuracy: Provides precise analog output signals with low basic and operating errors.
Galvanic Isolation: Ensures isolation between channels and the system, enhancing reliability and preventing ground loops.
Integrated Safety Shutdown: Offers a built-in safety mechanism for process shutdown in case of critical events.
Online Testing: The module is automatically and fully tested during operation, increasing system availability and safety.
Flexible Operation: Supports both source and sink modes, as well as redundant and bipolar current connections, catering to various application needs.
Robust Design: Suitable for industrial environments with an operating temperature range of 0 to +60 °C.
Compatibility: Designed for seamless integration with HIMA safety systems and various HIMA components.
