National Instruments 8234

National Instruments 8234

Product information：

Brand：NATIONAL INSTRUMENTS                           Model number：8234

Condition：new                              Warranty: 12 month

Lead Time：3-day working da        Country of origin: United States

Price: Please contact us                   Product weight：0.22kg

HS: 8517623990

Product technial information：

National Instruments NI PXIe-8234: Product Details, Specifications, Advantages, Precautions, and Applications

Product Details

The NI PXIe-8234 is a single-slot PXI Express module that provides two Gigabit Ethernet RJ45 ports. It's built on the Intel 82572EI (or similar, sometimes 82571EB) Ethernet controller, ensuring robust and low-latency network connectivity. This module is designed for seamless integration into PXI-based test and measurement applications, offering high-speed data transfer and reliable communication using standard copper cabling (CAT 5/6). It's compatible with 10BASE-T and 100BASE-TX networks while providing 1000 Mb/s (1000BASE-T) transfers.

Product Parameters (Specifications)

• Model Number: PXIe-8234 (also referred to as NI 8234, NI-8234)

• Interface: Dual Gigabit Ethernet (2 x RJ45 ports)

• Form Factor: Single-slot PXI Express/CompactPCI Express module

• Data Transfer Rate: Up to 1000 Mb/s (1 Gb/s) per port (1000BASE-T)

• PCI Express Interconnect: x4 PXI Express, providing up to 1 GB/s bandwidth

• Ethernet Controller: Intel 82572EI or 82571EB Gigabit Ethernet controller

• Compatibility:

• PXI Express and PXI Hybrid slots

• 10BASE-T and 100BASE-TX networks

• LabVIEW Real-Time compatible

• Operating Systems: Windows Vista/XP/2000/Me/NT/98 (for older systems, newer OS compatibility should be verified with NI)

• Features: Automatic cable polarity detection

• Physical Dimensions: Approximately 6.3 x 3.9 inches (Varies slightly by specific model/revision)

• Weight: Approximately 5.5 oz (Varies slightly)

• Operating Temperature: 0 to 55 °C

• Compliance: RoHS compliant

Product Advantages

• High-Speed Data Transfer: Offers two Gigabit Ethernet ports, enabling high-throughput data acquisition and communication.

• Optimized Performance: Utilizes Intel Ethernet controllers for low-latency networking and optimized performance, particularly with low CPU load.

• Space-Saving: Single-slot PXI Express module saves valuable slots in PXI/CompactPCI systems.

• GigE Vision Support: Fully supports the GigE Vision camera interface standard, allowing high-speed image transmission from multiple GigE Vision cameras simultaneously.

• Versatile Connectivity: Compatible with standard copper cabling (CAT 5/6) and various Ethernet standards, simplifying integration.

• Software Compatibility: Seamless integration with NI LabVIEW and Vision Acquisition Software, enabling rapid application development in various programming environments (LabVIEW, C, C++, C#, Visual Basic, .NET).

• Hybrid System Capability: The dual Ethernet ports allow for the development of hybrid test frameworks, integrating multiple buses and technologies into existing test setups.

• Automatic Cable Polarity Detection: Eliminates the need for manual crossover and straight-through cable swapping.
