National Instruments PXI-6251

National Instruments PXI-6251

Product information：

Brand：NATIONAL INSTRUMENTS                           Model number：PXI-6251

Condition：new                              Warranty: 12 month

Lead Time：3-day working da        Country of origin: United States

Price: Please contact us                   Product weight：0.22kg

HS: 8517623990

Product technial information：

National Instruments PXI-6251 Product Details

The National Instruments PXI-6251 is a high-speed multifunction data acquisition (DAQ) module belonging to the M Series. It's designed for applications demanding superior accuracy at fast sampling rates. This module offers a versatile set of analog I/O, digital I/O, counter/timer, and triggering functionalities within the PXI platform.

Product Parameters:

• Analog Input:

• Channels: 16 single-ended or 8 differential

• Resolution: 16 bits

• Maximum Sample Rate: 1.25 MS/s (single channel), 1 MS/s (multichannel aggregate)

• Input Ranges: ±0.1 V, ±0.2 V, ±0.5 V, ±1 V, ±2 V, ±5 V, ±10 V

• Input Coupling: DC

• Input Impedance: >10 GΩ in parallel with 100 pF (device on)

• Overvoltage Protection: ±25 V (device on, for up to four AI pins), ±15 V (device off)

• Analog Output:

• Channels: 2

• Resolution: 16 bits

• Maximum Update Rate: 2.86 MS/s (single channel), 2 MS/s per channel (two channels)

• Output Ranges: ±5 V, ±10 V, ±external reference on APFI 0

• Output Coupling: DC

• Output Impedance: 0.2 Ω

• Output Current Drive: ±5 mA

• Overdrive Protection: ±25 V

• Digital I/O:

• Number of Channels: 24 bidirectional

• Compatibility: TTL/CMOS

• Maximum Clock Rate: 10 MHz (software timed), up to 1 MHz (hardware timed, system and bus activity dependent)

• Direction Control: Individually programmable per terminal

• Input Voltage Protection: ±20 V (on up to two pins)

• Counter/Timers:

• Number of Counters: 2

• Resolution: 32-bit

• Maximum Source Frequency: 80 MHz

• Measurements: Edge counting, frequency, pulse width, period, two-edge separation, semi-period

• Triggering:

• Analog Triggering: Start, reference, pause triggers; analog edge and window triggering

• Digital Triggering: Start, reference, pause triggers; digital edge triggering

• PXI Bus Type: PXI Hybrid Compatible

• Data Transfer: DMA (scatter-gather), interrupts, programmed I/O

• Connector: 68-pin VHDCI female

• Calibration Interval: 2 years recommended

• Operating Temperature: 0 °C to 55 °C

• Weight: Approximately 221 grams (7.8 oz)
