AOIP TC6621

The AOIP TC6621 is a highly versatile and accurate temperature calibrator, primarily designed for both measurement and simulation of thermocouple signals and voltage. It's a robust instrument suitable for use in various industrial and laboratory settings.

Product Details

The AOIP TC6621 is a compact and portable device used for calibrating temperature measurement equipment. It can accurately measure and simulate a wide range of thermocouple types (including K, J, T, E, R, S, B, U, L) and voltage signals. Its design focuses on precision, reliability, and ease of use in the field.

Product Parameters

Here are some key specifications for the AOIP TC6621:

• Functions: Measures and generates thermocouple temperatures (16 different types), and voltage.

• Accuracy:

• Voltage: 0.020% of reading + 3 µV (for 100 mV range)

• Thermocouples: Typically 0.020% of reading + 0.35°C (CJC accuracy: ± 0.3°C)

• Temperature Ranges (Examples for various thermocouple types):

• K Type: -250°C to +1372°C

• J Type: -210°C to +1200°C

• T Type: -250°C to +400°C

• E Type: -250°C to +1000°C

• R Type: -50°C to +1768°C

• S Type: -50°C to +1768°C

• B Type: +400°C to +1820°C

• U Type: -200°C to +600°C

• L Type: -200°C to +900°C

• Resistance Ranges (for RTD models like TC6622, but relevant for understanding similar calibrators):

• 0 Ω to 400 Ω

• 0 Ω to 3600 Ω

• Dimensions (without sheath): 157 x 85 x 45 mm

• Weight: 306 g

• Environmental Protection: IP54 (dust and splash protected)

• Display: Selectable resolution up to 0.1 °C or 0.1 °F, with online help and probe connection assistance.

• Power Supply: 4 AA batteries or a battery/charger kit.

• Connectivity: USB socket for PC connection (software upgrade and data application with DATACAL).
