Bachmann MPC265

The Bachmann MPC265 is a high-performance processor module designed for demanding industrial automation systems. It's a core component within the Bachmann M1 controller system, known for its robustness and real-time capabilities.

Product Details

The MPC265 is a processor module manufactured by Bachmann, an Austrian company. It serves as the central processing unit for industrial control applications, offering powerful computation and reliable operation even in harsh environments. It is often supplied as a new and original component, typically with a 12-month warranty.

Product Parameters (Specifications)

The specifications for the Bachmann MPC265 can vary slightly depending on the specific revision and configuration, but generally include:

• Processor: Scalable multicore processors, with options ranging from single- to quad-core, up to 1.6 GHz clock frequency (some older versions may have lower clock speeds like 400/650/700 MHz Pentium class).

• RAM: Up to 2 GB DDR4 RAM (older versions might have 64 MB, 128 MB DRAM, or 256 MB DDR2).

• Storage:

• Up to 4 GB pSLC Flash (internal memory device, older versions 8 MB or 16 MB).

• CFast card slot for removable media (max 256 GB).

• Some versions may include 512 KB SRAM (battery-backed) and 64 KB FRAM.

• Interfaces:

• Ethernet: 1-3 ports (10/100/1000 Mbit/s with IEEE 1588).

• Serial: 1x RS232, 1x RS232/RS422/RS485.

• USB: 1x USB 3.0 (older versions 1x USB 2.0).

• CAN/CANopen

• Operating System: Typically runs on the VxWorks embedded real-time operating system.

• Power Consumption: Typically between 10.3 and 15.9 W (some sources indicate 15W or 17W for I/O power).

• Operating Temperature Range: Wide range, generally from -30°C to +60°C or even -40°C to +70°C, suitable for extreme conditions.

• Dimensions: Approximately 100 mm x 160 mm x 25 mm.

• Weight: Around 0.5 kg to 0.66 kg.

• Certifications: CE, UKCA, cULus, marine approvals.

• Programming: Supports IEC 61131-3 languages (IL, ST, LD, FBD, SFC, CFC), C/C++, and Java (Eclipse). Integrated with Bachmann SolutionCenter software.

Product Advantages

The Bachmann MPC265 offers several key advantages for industrial automation:

• High Performance: With scalable multicore processors and high clock frequencies, it delivers powerful processing capabilities for complex control tasks and real-time applications.

• Robustness and Reliability: Designed for demanding industrial environments, it offers exceptional durability, fanless operation, and a wide operating temperature range. This ensures fault-free operation even under harsh conditions.

• Real-time Symmetrical Multiprocessing: Enables precise and deterministic control, crucial for critical industrial processes.

• Scalability and Flexibility: Supports various processor configurations and memory options, allowing for tailored solutions based on application requirements. Its open architecture and support for various fieldbuses (e.g., PROFINET, CANopen, Modbus) provide flexible communication options.

• Extensive Connectivity: Multiple Ethernet, serial, and USB ports ensure versatile connectivity for integration into diverse systems.

• Ease of Integration: Seamlessly integrates into the Bachmann M1 system family and supports standard technologies like FTP, HTTP, SNTP, SMTP, and OPC.

• Long-term Availability: Bachmann designs its components for long-term availability and stability, offering investment protection.

• Advanced Programming Capabilities: Supports multiple programming languages and provides a comprehensive development environment (SolutionCenter), simplifying application development and maintenance.
