ENDRESS+HAUSER TMT112-A1KCA

ENDRESS+HAUSER TMT112-A1KCA

Product Description

The iTEMP HART TMT112 is a DIN rail temperature transmitter with HART® protocol. It is a universal transmitter that accepts inputs from resistance thermometers (RTD), thermocouples (TC), resistance transmitters (Ω), and voltage transmitters (mV), converting these signals into a scalable 4 to 20 mA analog output signal. It is designed for universal settings with HART® protocol for various input signals.

Product Parameters

• Input:

• Resistance thermometer (RTD) in 2-, 3-, or 4-wire connection (Pt100, Ni100, Pt500, Ni500, Pt1000, Ni1000)

• Thermocouple (TC) (Types K, J, T, E, L, U, N, C, D, R, S, B)

• Resistance transmitter (Ω) (10 to 400 Ω, 10 to 2000 Ω)

• Voltage transmitter (mV) (-10 to 75 mV)

• Output: 4 to 20 mA analog

• Communication: HART® protocol

• Power Supply: 12 to 35 V DC (standard version), 12 to 30 V DC (Ex version)

• Accuracy (for Pt100, -50 to 200 °C): ≤ ±0.2 K (≤ ±0.4 °F)

• Response Time: 1 s

• Ambient Temperature Range: -40 to +85 °C (-40 to +185 °F)

• Installation: DIN rail according to IEC 60715

• Galvanic Isolation: Yes (Input/output: $U=2kVAC$)

• Ex Approvals: ATEX Ex ia, CSA IS, FM IS (depending on the version)

• EMC: According to NAMUR NE 21, CE

• Safety: UL recognized component, CSA General Purpose, SIL (Transmitter)

Product Advantages

• Universal Settings: Suitable for various input signals due to HART® protocol.

• 2-wire Technology: 4 to 20 mA analog output simplifies wiring.

• High Accuracy: Ensures reliable measurement across the ambient temperature range.

• Fault Signal: Presettable to NAMUR NE 43 for sensor break or short circuit.

• EMC to NAMUR NE 21, CE: Ensures electromagnetic compatibility.

• Hazardous Area Approvals: Available with various Ex certifications (ATEX Ex ia, CSA IS, FM IS).

• Galvanic Isolation: Provides electrical isolation between input and output.

• Output Simulation: Allows for easy loop checking.

• Min./Max. Process Value Indicator: Tracks extreme process values.

• Customer-Specific Linearization: Adaptable to non-linear sensors.

• Linearization Curve Match: Improves accuracy for specific sensors.

Precautions

• Comply with the installation and safety instructions in the Operating Instructions.

• Install the device according to the manufacturer's instructions and any other valid standards and regulations (e.g., EN/IEC 60079-14).

• The housing of the thermometer must be connected to the local potential equalization or installed in a grounded metallic piping or tank.
