ENERPAC HPT1500

ENERPAC HPT1500 Product Details

The ENERPAC HPT1500 is a two-speed, high-pressure hydraulic hand pump equipped with a gauge. It is designed for applications requiring high force in a portable and manual package. This lightweight pump is particularly well-suited for use with hydraulic bolt tensioning tools and hydraulic nuts.

Product Parameters

Here are the key specifications of the ENERPAC HPT1500:

• Maximum Operating Pressure: 21,750 psi (1500 bar)

• First Stage Maximum Pressure: 200 psi

• Second Stage Maximum Pressure: 21,750 psi

• Usable Oil Capacity: 155 in³ (2.5 liters)

• Reservoir Capacity: 155 in³ (2.5 liters)

• Oil Displacement per Stroke (First Stage): 0.99 in³

• Oil Displacement per Stroke (Second Stage): 0.037 in³

• Gauge: Included

• Coupler: Included for direct connection to GT-Series bolting tools

• Valve Operation: Manual

• Port Size: 1/4" NPT

• Handle Material: Aluminum

• Weight: 19 lbs (8.6 kg)

• Operating Orientation: Horizontal and Vertical

Product Advantages

The ENERPAC HPT1500 offers several key advantages:

• High Pressure Output: Capable of delivering up to 21,750 psi (1500 bar), making it ideal for demanding applications like bolt tensioning.

• Two-Speed Operation: Features a two-stage pumping mechanism. The first stage provides high oil displacement for quickly advancing the hydraulic system, while the second stage delivers high pressure with lower displacement for controlled force application. This reduces cycle times compared to single-speed pumps.

• Lightweight and Portable: Its aluminum construction makes it easy to carry and maneuver, especially in applications where a power source is not readily available.

• Integrated Gauge: The built-in pressure gauge allows for precise monitoring of the applied pressure, enhancing safety and accuracy.

• Direct Connection to GT-Series: Comes with a coupler specifically designed for direct connection to Enerpac GT-Series bolt tensioning tools, ensuring compatibility and ease of use.

• Integrated Relief Valve: An internal relief valve is set at 21,750 psi to protect the pump from over-pressurization.

• Versatile Operation: Can be operated in both horizontal and vertical positions, and can be used as a vented or non-vented pump.

• Durable Construction: Built with high-quality materials for long-lasting performance in tough industrial environments.
