IME TM8POH110

IME TM8POH110 Product Details

The IME TM8POH110 is a programmable transducer designed for measuring active and reactive power, frequency, phase angle, and power factor (cosfi) in electrical networks. It is part of the TEMA fP series from IME. This transducer can be used in both single-phase and three-phase (3 or 4 wires, balanced or unbalanced) systems. Its compact design occupies 8 DIN modules.

Product Parameters

Here are the key technical parameters of the IME TM8POH110:

• Brand: IME

• Series: TEMA fP



• Type: Programmable Transducer for Active and Reactive Power, Frequency, Phase Angle, Cosfi



• Network: Single-phase or Three-phase (3/4 wires, balanced or unbalanced)



• Input Voltage: 80-500Vac



• Input Current: 1A



• Output: 0-5V



• Auxiliary Supply: 20-150Vdc



• Frequency: 45-65 Hz



• Accuracy Class: 0.5



• Power Loss: 4.8 W



• Dimensions: 8 DIN modules



• Housing Material: Polycarbonate (PC)



• Operating Temperature: -25 to 70 °C

• Storage Temperature: -25 to 70 °C



• Certifications: Complies with IEC standards and European Directives (LVD: 2014/35/EU)



Product Advantages

• Versatile Measurement: Measures a comprehensive range of electrical parameters including active and reactive power, frequency, phase angle, and power factor.

• Programmable Range: The measurement range is programmable, offering flexibility for various applications.



• Wide Compatibility: Suitable for both single-phase and three-phase systems, balanced or unbalanced.



• Compact Design: The 8 DIN module size allows for efficient use of panel space.

• High Accuracy: Class 0.5 accuracy ensures reliable and precise measurements.



• Compliance with Standards: Meets international IEC standards and European safety directives.



• Easy Installation: Designed for DIN rail mounting.

Precautions

While specific precautions for the TM8POH110 were not explicitly detailed in the search results, general precautions for electrical transducers should be observed:

• Proper Installation: Installation should be carried out by qualified personnel according to the manufacturer's instructions and relevant electrical safety standards.

• Correct Wiring: Ensure correct wiring connections to avoid damage to the transducer and ensure accurate measurements.

• Operating Conditions: Operate the transducer within its specified voltage, current, and temperature ranges.

• Protection: Provide appropriate protection against overcurrent and overvoltage.

• Calibration: Regular calibration may be required to maintain accuracy. Refer to the user manual for calibration procedures and intervals.

• Safety: Always disconnect power before performing any installation or maintenance work.
