LENZE EVD532-E

LENZE EVD532-E Product Details

The LENZE EVD532-E is a compact and reliable speed controller designed for controlling DC motors. It belongs to the Lenze 530 series of controllers. This unit provides efficient and precise speed adjustment for various industrial applications.

Product Parameters

Here are some key technical specifications for the LENZE EVD532-E:

• Model Type: Lenze 530

• Part Number: EVD532-E / 13060307

• Input Voltage: 1/N/PE AC 230V (190...265V), 50/60 Hz (can be adjusted to 100...132V with a solder link)

• Output Voltage 1: DC 0-180V

• Output Current 1: 2A

• Output Voltage 2: DC 210V

• Output Current 2: 0.3A

• Output Power: 0.36 kW (0.5 HP)

• Control Method: Armature voltage feedback or tacho feedback with $I\times R$ compensation

• Ambient Temperature (Operation): 0...+45 °C

• Dimensions: 5.1 cm x 15.2 cm x 12.7 cm (2.0 in x 6.0 in x 5.0 in)

• Weight: Approximately 0.4 kg (0 lbs 13.0 oz)

• Protection Class: IP00

• Mounting: Mounting plate or DIN rail 35 x 7.5 mm

• Connections: Screwless, vibration-proof plug and socket connectors

• Fuse Type: FF6.3 / 250V

Product Advantages

The LENZE EVD532-E offers several benefits:

• Precise Speed Control: Allows for accurate adjustment of DC motor speeds to meet specific application requirements.

• Compact Design: Its single-board design saves space and simplifies installation.

• Easy Connection: Features screwless plug and socket connectors for quick and reliable wiring.

• Robust and Reliable: Designed for industrial environments with a protective cover to prevent accidental contact with live components.

• Flexible Feedback Options: Supports both tacho and armature voltage feedback, offering adaptability to different motor types and application needs.

• Compensation for Load Changes: The $I\times R$ compensation feature helps maintain consistent speed under varying loads.

• Operational Integrity: Maintains stable operation even with mains voltage fluctuations.
