Bachmann PCC201

The Bachmann PCC201 is a PC card designed as a removable memory storage medium primarily for Bachmann M1 and M200 series controllers. It's an integral component for storing operating systems, drivers, application software, source codes, and documentation within these industrial control systems.

Product Details

The PCC201 PC card serves as an external storage solution for Bachmann's industrial controllers. It enables easy transfer of programs and data, making it convenient for system setup, maintenance, and data backup. Bachmann emphasizes that the PCC201 series is produced in-house, ensuring long-term supply and compatibility within their ecosystem.

Product Specifications

• Memory Capacity: Available in 32 MB and 64 MB versions.

• Memory Type: Likely solid-state flash memory, designed for durability and resistance to shock and vibration in industrial environments.

• Access Width: 16-bit.

• Operating Voltage: 5 V (with a minimum of 3 V for FLASH memory).

• Program Voltage: 12 Vss.

• Write Protection: Achieved via operating software.

• Data Retention: Important for critical program storage, though specific retention periods might require referring to the detailed datasheet.

• Write Endurance: While not always explicitly stated, industrial-grade memory cards like the PCC201 are designed for a high number of write/erase cycles.

• Environmental Conditions:

• Operating Temperature: 0 °C to +60 °C

• Storage Temperature: -40 °C to +85 °C

• Relative Humidity (Operation/Storage): 5% to 95% non-condensing.

• Approvals: CE, UKCA, cULus.

• Compatibility: Designed for use with Bachmann M1 and M200 controller series. Can also be used in PCMCIA slots of PCs and notebooks with an A-PCC200 adapter.

Product Advantages

• Reliability: As an in-house Bachmann product, it's designed and manufactured to meet the specific demands and harsh conditions of industrial automation, ensuring robust performance.

• Durability: Utilizes solid-state flash memory, offering better resistance to shock and vibration compared to traditional storage media, which is crucial in industrial settings.

• Long-Term Availability: In-house production guarantees a consistent and long-term supply, reducing concerns about obsolescence for critical industrial systems.

• Seamless Integration: Specifically engineered for Bachmann M1 and M200 controllers, ensuring perfect compatibility and optimal performance within the Bachmann automation platform.

• Data Security: Features write protection via operating software, helping to prevent unintended data corruption or unauthorized modifications.

• Versatility: Can be directly written to and formatted in all processor modules of the M1 and M200 controllers. The optional A-PCC200 adapter allows for use with standard PCs and notebooks.
