SCHNEIDER 170ADI35000


Product information：

Brand：SCHNEIDER                              Model number：170ADI35000

Condition：new                              Warranty: 12 month

Lead Time：3-day working da        Country of origin: France

Price: Please contact us                   Product weight：0.37kg

HS: 8517623990


Product technial information：


SCHNEIDER 170ADI35000



SCHNEIDER 170ADI35000 Product Details

The SCHNEIDER 170ADI35000 is a discrete input base DC module belonging to the Modicon Momentum automation platform. It serves as an interface to receive digital signals from field devices in industrial control systems. This module offers 32 input channels, organized into two groups of 16 inputs each, and adheres to the IEC 1131-2 Type 1 standard with positive discrete input logic. It operates with a 24 V DC input voltage. The module provides 500 V AC isolation between channels and the bus, enhancing system reliability. It features 32 LEDs for easy monitoring of the status of each input channel. Designed for wall mounting, this module is a component of a flexible and modular system that can be easily configured for various distributed I/O and control applications.


Product Parameters

ParameterValue
Range of ProductModicon Momentum automation platform
Product or Component TypeDiscrete inputs base DC
Group of Channels2 groups of 16 inputs
Discrete Input Number32 IEC 1131-2 Type 1
Discrete Input Voltage24 V DC
Discrete Input LogicPositive
Input Voltage Limits24 V
Voltage Range-3...30 V
Voltage State 0 Guaranteed-3...5 V
Voltage State 1 Guaranteed11...30 V
Current State 0 Guaranteed<= 1.2 mA
Current State 1 Guaranteed>= 2.5 mA
Input Resistance4 kOhm
Response Time (0 to 1)2.2 ms
Response Time (1 to 0)3.3 ms
Isolation500 V AC between channels and bus
Power Dissipation (Typical)5.5 W
Power Dissipation (Maximum)8.5 W
Local Signaling32 LEDs for channel status
Current Consumption<= 250 mA at 24 V DC
Width125 mm (4.9 in)
Height141.5 mm (5.6 in)
Depth47.5 mm (1.9 in)
Net Weight0.2 kg (0.4 lb)
Operating Temperature0...60 °C (32...140 °F)
Storage Temperature-40...85 °C (-40...185 °F)
Relative Humidity95 % without condensation
Operating Altitude<= 5000 m (<= 16404.2 ft)
CertificationsCE, CSA, UL
Protective TreatmentTC (Conformal coating available on 170ADI35000C)
