SCHNEIDER TCSESM163F2CU0

SCHNEIDER TCSESM163F2CU0

Product information：

Brand：SCHNEIDER                              Model number：TCSESM163F2CU0

Condition：new                              Warranty: 12 month

Lead Time：3-day working da        Country of origin: France

Price: Please contact us                   Product weight：0.66kg

HS: 8517623990

Product technial information：

SCHNEIDER TCSESM163F2CU0 Product Details

The SCHNEIDER TCSESM163F2CU0 is a ConneXium managed Ethernet TCP/IP switch. It features 14 ports for copper cables (10/100BASE-TX) and 2 ports for multi-mode fiber optics (100BASE-FX). This switch provides a smart and flexible way to integrate Ethernet solutions into your industrial operations.

Product Parameters

• Range of Product: ConneXium

• Product or Component Type: Ethernet TCP/IP managed switch

• Concept: Transparent Ready

• Communication Port Protocol: Ethernet TCP/IP, SSH, HTTP, HTTPS, SNMP, RS232, LLDP, Telnet, SNTP, MRP (Media Redundancy Protocol)



• Port Ethernet:



• 14 ports 10/100BASE-TX for copper cable

• 2 ports 100BASE-FX for multi-mode fiber optic

• Maximum Number of Switches in Cascade: Unlimited

• Cybersecurity: Port hardening

• Integrated Connection Type:

• Shielded RJ45 for copper cable

• Duplex SC for fiber optic

• Transmission Support Medium:

• Twisted shielded pair CAT 5E for copper cable

• Multimode optical fiber for fiber optic

• Maximum Cable Distance Between Devices: 100 m (copper cable)

• Optic Fiber Length: 4 km (62.5/125 µm), 5 km (50/125 µm)

• Attenuation: 0-11 dB (62.5/125 µm), 0-8 dB (50/125 µm)



• Ethernet Services: Configuration via web server, VLAN, Multicast filtering, Data stream control, IGMP Snooping, SNMP-Traps and SYSLOG

• Communication Services: TFTP, Quality of Service (QoS), Port monitoring, Port mirroring, Address conflict detection



• Diagnostics Run Time: Self test, Signal contact

• Maximum Number of Switches in a Ring: 50

• Redundancy: HiPER ring, RSTP, Redundant network coupling

• [Us] Rated Supply Voltage: 12...48 V DC SELV, 18...30 V AC SELV



• Supply Voltage Limits: 9.6...60 V DC SELV, 18...30 V AC SELV

• Power Consumption: 11.8 W

• Electrical Connection: Removable connector, 6 ways (power supply)

• Mounting Support: 35 mm symmetrical DIN rail

• Marking: CE, UL, RCM, EtherNet/IP

• Function Available: Alarms (Traps), System information, Report, Trap log

• Local Signaling: LEDs for power supplies, fault, ring manager, stand-by, link status, and activity per channel



• Device Status: Alarm output (1 volt-free contact 1 A)

• Alarm Function: Power supply fault, Data link status, Redundancy ring fault, Switch fault

• Ethernet Cabling System: TF switches

• Width: 111 mm



• Height: 131 mm

• Depth: 111 mm

• Net Weight: 0.6 kg



• IP Degree of Protection: IP20

• Operating Temperature: 0...60 °C

• Relative Humidity: 10...95% non-condensing

• Certifications: CE, UL, RCM, ODVA EtherNet/IP, BV, GL

• Standards: UL 508, EN/IEC 61131, IEC 61850-3
