SIEMENS 6ES7317-6FF04-0AB0

SIEMENS 6ES7317-6FF04-0AB0

Product information：

Brand：Siemens                              Model number：6ES7317-6FF04-0AB0

Condition：new                              Warranty: 12 month

Lead Time：3-day working da        Country of origin: Germany

Price: Please contact us                   Product weight：0.37kg

HS: 8517623990

The Siemens 6ES7317-6FF04-0AB0 is a SIMATIC S7-300 CPU 317F-2DP central processing unit, an essential component in Siemens' well-established S7-300 series of programmable logic controllers (PLCs). This CPU is designed for complex automation tasks, particularly those requiring functional safety.

Product Description

The 6ES7317-6FF04-0AB0 is a robust CPU module for the SIMATIC S7-300 system. It features 1.5 MB of integrated work memory and comes with two interfaces: a first interface for MPI/DP (Multi-Point Interface/Distributed Periphery) at 12 Mbit/s, and a second interface configured as a DP master/slave. This CPU requires a Micro Memory Card (MMC) for operation and for storing the program. It is specifically designed to be used with safety-related applications, requiring the software package S7 Distributed Safety V5.2 SP1 or higher.

Product Parameters (Specifications)

Here are some key technical parameters for the Siemens 6ES7317-6FF04-0AB0:

• Product Type: Central Processing Unit (CPU)

• Series: SIMATIC S7-300

• Model: CPU 317F-2DP (F indicates Fail-safe)

• Work Memory: 1.5 MB (integrated)

• Load Memory: Requires a plug-in Micro Memory Card (MMC), max. 8 MB

• Interfaces:

• Interface 1: MPI/DP (PROFBUS DP), 12 Mbit/s

• Interface 2: DP Master/Slave (PROFIBUS DP)

• Supply Voltage (DC):

• Rated Value: 24 V DC

• Permissible Range: 19.2 V to 28.8 V DC

• Current Consumption (rated value): Approximately 870 mA

• Power Loss (typical): Approximately 4.5 W

• CPU Processing Times (typical):

• Bit Operations: 0.025 µs

• Word Operations: 0.03 µs

• Fixed Point Arithmetic: 0.04 µs

• Floating Point Arithmetic: 0.16 µs

• Counters (S7): 512

• Timers (S7): 512

• DBs (Data Blocks): Max. 2048, up to 64 KBytes each

• FBs (Function Blocks): Max. 2048, up to 64 KBytes each

• FCs (Functions): Max. 2048, up to 64 KBytes each

• Programming Software: Requires STEP 7 V5.5 + SP1 or higher, along with S7 Distributed Safety V5.2 SP1 or higher.

• Firmware Version: As of V3.3.17 (can be updated via MMC or online with STEP 7)

• Dimensions (approx.): 40 mm (W) x 125 mm (H) x 130 mm (D)

• Net Weight (approx.): 0.416 kg

• Product Lifecycle: PM400: Announcement of product phase-out (as of October 1, 2023),
