SIEMENS 6ES7972-0BA61-0XA0

SIEMENS 6ES7972-0BA61-0XA0

Product information：

Brand：Siemens                              Model number：6ES7972-0BA61-0XA0

Condition：new                              Warranty: 12 month

Lead Time：3-day working da        Country of origin: Germany

Price: Please contact us                   Product weight：0.03kg

HS: 8517623990

The SIEMENS 6ES7972-0BA61-0XA0 is a PROFIBUS bus connector designed for industrial automation applications. It's a key component for establishing reliable communication in PROFIBUS DP networks.

Product Details

This connector is specifically a SIMATIC DP connection plug for PROFIBUS, supporting data transfer rates up to 12 Mbit/s. A notable feature is its 35-degree cable outlet, which is often beneficial for specific cable routing requirements in control cabinets or tight spaces. It utilizes the FastConnect insulation displacement method, allowing for quick and easy installation without the need for stripping individual wires. Importantly, this particular model does not include a PG (programming device) socket.

Product Parameters

• Type: PROFIBUS Bus Connector

• Part Number: 6ES7972-0BA61-0XA0

• Supported Protocol: PROFIBUS DP

• Max Data Transfer Rate: Up to 12 Mbit/s

• Cable Outlet Angle: 35 degrees

• Connection Method: FastConnect (insulation displacement method)

• PG Socket: No

• Dimensions (WxHxD): Approximately 15.8 mm x 54 mm x 39.5 mm

Product Advantages

• Reliable PROFIBUS Connection: Provides a robust and secure connection for PROFIBUS DP networks, essential for industrial communication.

• FastConnect Technology: Enables quick and error-free wiring due to the insulation displacement method, significantly reducing installation time and effort.

• Space-Saving Design: The 35-degree cable outlet can be advantageous in confined spaces, allowing for more flexible cable routing and a neater installation.

• High Data Rate Support: Supports PROFIBUS communication up to 12 Mbit/s, suitable for most industrial automation applications requiring fast data exchange.

• Siemens Quality: As a Siemens product, it benefits from the company's reputation for high quality, reliability, and compatibility within the SIMATIC automation system.

Precautions

• Proper Installation: Ensure the FastConnect method is used correctly to guarantee a secure and reliable connection. Incorrect termination can lead to communication errors.

• Cable Type: Use only PROFIBUS cables specified for FastConnect technology to ensure proper operation and avoid damage to the connector.

• Environmental Conditions: While designed for industrial environments, ensure the connector is used within its specified operating temperature and humidity ranges to prevent malfunction.

• No PG Socket: Be aware that this model lacks a PG socket. If on-the-fly programming or diagnostics are required at the connection point, a connector with a PG socket (e.g., 6ES7972-0BBxx-0XA0 series) might be more suitable.

• Network Termination: Remember that PROFIBUS networks require proper termination at both ends of the bus segment to prevent signal reflections and ensure stable communication.

Product Applications

The SIEMENS 6ES7972-0BA61-0XA0 connector is widely used in various industrial automation scenarios where PROFIBUS DP communication is essential, including:

• Factory Automation: Connecting PROFIBUS-enabled devices like PLCs, HMIs, drives, and sensors in manufacturing plants.

• Process Control: Establishing communication in process automation systems for data acquisition, control, and monitoring.

• Machine Building: Integrating various components and modules within machines that utilize PROFIBUS for control and data exchange.

• Building Management Systems: In some industrial building automation contexts where PROFIBUS is employed.

• Distributed I/O Systems: Connecting distributed I/O modules to a central PLC over a PROFIBUS network.
