SIEMENS 6GF3440-8BA2

SIEMENS 6GF3440-8BA2

Product information：

Brand：Siemens                              Model number：6GF3440-8BA2

Condition：new                              Warranty: 12 month

Lead Time：3-day working da        Country of origin: Germany

Price: Please contact us                   Product weight：0.03kg

HS: 8517623990

The Siemens 6GF3440-8BA2 is a Power-, DI/DO-, RS232-cable designed for use with Siemens MV 400 series devices. Here's a detailed overview:

Product Description

The 6GF3440-8BA2 is a 10-meter long communication line (12-core) that facilitates the wiring of 24 V power, RS232 communication, and digital input/output (DI/DO) signals for customer-side connections. It comes with an M16 12-pole connector pre-assembled on one end, with the other end left as bare strands for flexible termination.

Product Parameters

• Product Type Designation: Power-, DI/DO-, RS232-cable, open strands / M16 12-pole

• Cable Designation: Li2YC 11Y

• Wire Length: 10 meters

• Electrical Connections: 1 (M16 pre-assembled, bare end)

• Operating Voltage (Maximum): 30 V

• Number of Electrical Cores: 12

• Shield Design: Braided shield made of tin-plated copper wires

• Outer Diameter of Cable Sheath: 7.8 mm (symmetrical tolerance 0.2 mm)

• Material of Wire Insulation: Polyethylene (PE)

• Material of Cable Sheath: PUR (Polyurethane)

• Color of Cable Sheath: Black

• Ambient Temperature (Operation, Storage, Transport): -25 to +70 °C

• Ambient Temperature (Installation): -5 to +70 °C

• Halogen-free: Yes

• RoHS Compliant: Yes

Product Advantages

• Integrated Connectivity: Combines power, digital I/O, and RS232 communication into a single cable, simplifying wiring and reducing clutter for MV 400 devices.

• Robust Design: Features a PUR outer sheath and braided shield, offering good mechanical protection and resistance to harsh industrial environments.

• Flexibility: The bare end allows for customized termination on the customer side, adapting to various installation requirements.

• Compatibility: Specifically designed for seamless integration with Siemens MV 400 series devices, ensuring reliable performance.

• Halogen-Free: Contributes to improved safety in case of fire, as it emits fewer toxic and corrosive gases.

Precautions

• Installation by Specialists: Installation should only be performed by qualified personnel with specialist electrotechnical knowledge to ensure proper and safe operation.

• Proper Use: Ensure the cable is used only for the applications described in the product documentation. Using it for unintended purposes may lead to damage or malfunction.

• Environmental Conditions: Adhere to the specified ambient temperature ranges during operation, storage, transport, and installation to prevent damage and ensure longevity.

• Voltage Limits: Do not exceed the maximum operating voltage of 30 V to prevent electrical hazards and damage to connected equipment.

• Mechanical Stress: Avoid excessive bending or pulling that could damage the cable's internal structure or insulation.

• Disposal: Dispose of the cable and any associated components in an environmentally friendly manner, adhering to national guidelines and regulations.

Product Applications

The Siemens 6GF3440-8BA2 cable is primarily used in industrial automation settings for connecting Siemens MV 400 series vision systems and identification readers. Specific applications include:

• Machine Vision Systems: Providing power, I/O, and serial communication for barcode readers, 2D code readers, and other vision sensors used in manufacturing, logistics, and quality control.

• Industrial Identification: Connecting readers for RFID or optical identification in production lines, material handling, and tracking systems.

• Integration with PLCs/Controllers: Facilitating the exchange of data and control signals between MV 400 devices and programmable logic controllers (PLCs) or other industrial control systems via RS232 and digital I/O.

• Automated Production Lines: Essential for reliable communication and power supply in automated processes where MV 400 devices are used for inspection, verification, or data acquisition.
