National Instruments PXI-6238

National Instruments PXI-6238

Product information：

Brand：NATIONAL INSTRUMENTS                           Model number：PXI-6238

Condition：new                              Warranty: 12 month

Lead Time：3-day working da        Country of origin: United States

Price: Please contact us                   Product weight：0.15kg

HS: 8517623990

Product technial information：

The National Instruments (NI) PXI-6238 is a PXI M Series Multifunction I/O Module designed for accurate measurements and precise control in demanding test, measurement, and control applications. It is particularly well-suited for environments with high voltages and electrical noise due to its bank isolation features.

Product Details

The NI PXI-6238 (Part Number: 779624-01) is a 3U PXI multifunction I/O module. It's part of the M Series, known for integrating various I/O capabilities into a single device. A key feature is its bank isolation, which provides safety and performance benefits by isolating different I/O banks, especially crucial in noisy or high-voltage environments. It includes analog I/O, digital I/O, and counter/timer functionalities.

Product Specifications

Here are the key specifications for the NI PXI-6238:

• Analog Input (AI):

• Channels: 8 differential current input channels.

• Resolution: 16 bits.

• Maximum Sample Rate: 250 kS/s.

• Input Range: ±20 mA.

• Input Coupling: DC.

• Timing Accuracy: 50 ppm of the sample rate.

• FIFO Buffer Size: 4095 samples.

• Overcurrent Protection: ±40 mA maximum.

• Overvoltage Protection: ±25 V (device on), ±15 V (device off) for up to two AI pins.

• Analog Output (AO):

• Channels: 2 current output channels.

• Resolution: 16 bits (DAC).

• Maximum Update Rate: 500 kS/s (single channel), 450 kS/s (per channel, dual channel).

• FIFO Buffer Memory: 8191 samples.

• Digital I/O (DIO):

• Channels: 6 digital input (DI) and 4 digital output (DO) lines.

• Compatibility: 24 V signals.

• Digital Input Range: 0 V to 30 V.

• Maximum Digital Output Current Drive: 350 mA (single line), 100 mA (each line for simultaneous usage).

• Device Output Type: DO source.

• Counters/Timers:

• Number: 2.

• Resolution: 32 bits.

• Capabilities: Edge counting, pulse, semi-period, period, two-edge separation, quadrature encoding (X1, X2, X4).

• Internal Base Clocks: 80 MHz, 20 MHz, 0.1 MHz.

• External Base Clock Frequency: 0 MHz to 20 MHz.

• Base Clock Accuracy: 50 ppm.

• Data Transfer: DMA (scatter-gather), interrupts, programmed I/O.

• Operating Temperature Range: 0 °C to +55 °C.

• Form Factor: Standard 3U PXI.

• Warranty: Typically 2-3 years.
